| 產品規(guī)格 | 圖號 | 偏距 | 中心孔 | 分布圓 | 螺栓孔 |
| SIZE | CODE | OFFSET | CENTER HOLE | P.C.D | BOLT HOLE |
| 8x2.5 | 08025006 | -2 | φ85 | φ115 | 4-φ12.5 |
| 8x3.75 | 08037501 | -2 | φ68.5 | φ114.3 | 5-φ15 |
| 8x3.75 | 08037502 | -2 | φ72 | φ101.6 | 4-φ15 |
| 8 x3.75 | 08037515 | -2 | φ64 | φ101.6 | 4-φ15 |
| 8x7 | 08070003 | -2 | φ72 | φ101.6 | 4-φ15 |
| 8x7 | 08070004 | -2 | φ72 | φ114.3 | 5-φ15 |
| 8x7 | 08070009 | -2.5 | φ72 | φ114.3 | 5-φ15 |
| 8x8.5 | 08085009 | -2 | φ72 | φ114.3 | 5-φ15 |
| 12x4 | 12040001 | 0 | φ75 | φ114.3 | 5-φ14.3 |
| 12 x4 | 12040002 | 0 | φ68.5 | φ101.6 | 4-φ14.3 |
| 12x4 | 12040003 | 0 | φ75 | φ114.3 | 5-φ14.3 |
| 12x4 | 12040016 | 0 | φ72 | φ114.3 | 5-φ14.3 |
| 12x4 | 12040018 | 0 | φ75 | φ114.3 | 5-φ14.3 |
| 12x4 | 12040019 | 0 | φ68.5 | φ101.6 | 4-φ14.3 |
| 12x4 | 12040021 | 0 | φ75 | φ114.3 | 5-φ14.3 |
| 13x4.5 | 13045001 | 0 | φ81 | φ114.3 | 5-φ14.3 |
